LED Outdoor Lighting
Circular LED Wall Light Bulkhead Light for Widely Use
  • Circular LED Wall Light Bulkhead Light for Widely Use
  • Circular LED Wall Light Bulkhead Light for Widely Use
  • Circular LED Wall Light Bulkhead Light for Widely Use
  • Circular LED Wall Light Bulkhead Light for Widely Use
  • Circular LED Wall Light Bulkhead Light for Widely Use
Circular LED Wall Light Bulkhead Light for Widely Use
Model: WD-BL-Circular-8W
Port:Zhongshan, China
Production Capacity:20000 PCS
Payment Terms:L/C, T/T, Western Union, Paypal
Style:Modern
Color Temperature:Cw,Ww
Lamp Body Material:Plastic + PC
Shape:Round, Oval
Irradiated Area:3-5㎡
Switch Type:Rotary/Button
Description

Basic Info

Model NO.
WD-BL-Circular-8W
Base Type
SMD
IP Rating
IP54
Shade Type
PC Cover
Certification
CE, RoHS
Voltage
AC100-240V
Application
Bathroom, Spar Room, Home, Corridor, Station, Dock
Trademark
WORLD-DAWN
Transport Package
Inner Box+Export Outer Box
Specification
176*55mm
Origin
Made in China
HS Code
9405409000

IP54 round Led ceiling bulkhead lamp


Features:

1.Elegant design, classic trend.
2.Good color rendering index and without glare.
3.Long lifetime.
4.Easy installation and maintain.
5.IP54,Strong thermal conductivity and anti-corrosion.
6.High quality diffusion material for lampshade, with high light transmittance.
7.Application for public area indoor or outdoor.
8.Replacement of traditional bulbs and no subsidiary fixture, such as ballasts and starters.


Advantage:

1) 100% sealed lighting system, resistant to moisture, dirt and dust ingress
2) Back of the housing has large cooling ribs for optimized heat dissipation
3) Reverse battery and over-voltage protection
4) High durability with low maintenance
5) Cover color available: Black, white
6) Application:Widely use for bathroom, spar room, home, corridor, station, dock, toilet, shower room, outdoor landscape, etc.


Basic Info.:


 Model  WD-BL-Circular-8W
 Input Voltage  AC100-240V
 Input Current  100mA
 Power  8W
 Power Factor  ≥0.5
 CRI  Ra: 80
 Lumen  550lm
 Beam Angle   115°
 IP Rating  IP54
 Color Temperature  3000-6500K

Installtion:



Application:
