LED Panel Light
High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
  • High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
  • High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
  • High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
  • High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
  • High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
  • High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
Model: WD-STP01-R-15W
Min. Order: 40 Pieces
Port: Zhongshan, China
Transport Package: Customized Packing / Neutro-Packing
Payment Terms: L/C, T/T, Western Union, Paypal, Money Gram
Light Source: LED
Housing Material: Aluminum
Emitting Color: White,Warm White
Dimmable: With Dimmable
Appearance: Round/Square
Type: Ceiling
Description

Basic Info

Model NO.
WD-STP01-R-15W
Base Material
Aluminum
Certification
CE, RoHS
Beam Angle
120
Wattage
3W,6W,9W,12W,15W,18W,24W
Trademark
World-Dawn
Specification
CE, ROHS
Origin
Guangdong
HS Code
9405409000

15W Ultra-thin LED Panel Ligh, small LED Panel
Model No.: WD-STP01-R-15W

High Quality Round Shape LED Panel Light (WD-STP01-R-15W)
Features:



  • Super thin, small size to save space.
  • side lighting, using reflective light leading board, no glare, eyes protecting.
  • Use constant current driver, no stroboflash.
  • wide voltage 85~265V, world-wide use.
  • Die casting aluminum housing, good heat dissipation.
  • replace downlight directly.
  • PMMA Light Guide Plate, PMMA diffuser
  • Shape: Round, Squar
  • Wattage: 12W (others 3W, 6W, 9W, 15W, 18W, 24W also available
Installation:


High Quality Round Shape LED Panel Light (WD-STP01-R-15W)

Note:

        1. Indoor application in dry environment only.

        2. Do not cover flammable materials over lamp.

        3. Make sure the power is off when processing installation.

        4. Professional maintenance personnel is required if repair is needed.

Applications:



Hotels.
Conference / Meeting rooms.
Factories & Offices.
Commercial Purposes.
Residential / Institution Buildings.
Schools, Colleges & Universities.
Supermarket Lighting.
High Quality Round Shape LED Panel Light (WD-STP01-R-15W)

  Item No.:    WD-STP01-R-15W
  Input voltage:   AC100-245V
  LED chip:   Epistar -SMD2835
  LED Qty:   90 Pieces
  Power:  18W
  CRI:   ≥75
  Protection Grade:   IP44
  Lamp Size:   Φ 200mm*H20mm
  Hole size:   Φ 185mm
  Beam Angle:   120°
  Harmonic :   ≤ 10%
  Power factor:   ≥ 0.9
  Warranty  2 years
  Luminous Flux:   80lm/wattage Warm white
  85lm/wattage Pure white
  Color temperature:   2700-3000K Warm white
  6000-6500K Pure White
  Housing Material:   Die-casting Aluminum
  Base Material:   PMMA LGP,PMMA Diffuser
  Shape   Round / Square
  Interface:   Terminal
  Dimming:   Optional(yes/no)
  Installation:   Embedded
  Storage temperature:   -20   °C  to +60   °C
  Working temperature:   -20  °C     to +40   °C
  Life:   > 50,000 hours
