IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
  • IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
  • IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
  • IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
  • IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
  • IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
  • IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
Model: SMD5050-3-IP65-IM-D
Min. Order: 2,000 Pieces
Port: Zhongshan, China
Production Capacity: 100000 Meters/ Per Month
Payment Terms: L/C, T/T, Western Union, Paypal, Money Gram
LED Light Source: SMD
Emitting Color: Red,Green,Blue,RGB
1 LED Power: 0.24W
Power: 0.72W
LED Chips: Epistar
IP Rating: IP65
Description


Basic Info

Model NO.
SMD5050-3-IP65-IM-D
Waterproof
Waterproof
Size
75*15mm
Port
Zhongshan
Original
China
Color
as Show
Life Span
2y
Chip Brand
Epistar
Label
Wd
Trademark
WORLD-DAWN
Specification
75X15MM
Origin
China
HS Code
9405409000


Specifications
1. LED QTY: 3leds/pcs
2. Warranty: 2years
3. 5050 LED, Injection waterproof, no UV/IR
4. CE, RoHS
5 Color: Red Green Blue Cold White Warm white RGB
6.Lamp Lumen:60LM
7.Input voltage:DC12V
8.Power:0.72w/pcs
9.Working Temperature:-40-60
10.Beam angle 120 degree

IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDsIP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDsIP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs

Feature
1. Unique integrated design
2. Creative LED anti-static packaging
3. Tremendous energy saving
4. Long life, Up to 50, 000 hours,
5. No strobe flashing
6. Green and Environmental protection
7. Impact resistance, shock-proof, without UV

IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs

Applications
1. Lighting up romantic and colorful life, DIY for hallways, stairs, ceiling, showcase, drawer etc.
2. Widely decorate in hotels, theaters, clubs, shopping malls, entertainment centre, festivals and performances, also the clothes.
3. Architectural decorative in archway, canopy and bridge edge, security lighting and emergency also is the very good choice
4. More and more decorate the automobile & airplane model decoration,
5. Advertisement use in contour lighting or border

IP65 High Brightness LED Module with CE Approval for SMD5050 3 LEDs
