LED Strip Light
SMD3528-60LED/M-IP68-Warm White LED Strip Light
  • SMD3528-60LED/M-IP68-Warm White LED Strip Light
  • SMD3528-60LED/M-IP68-Warm White LED Strip Light
  • SMD3528-60LED/M-IP68-Warm White LED Strip Light
  • SMD3528-60LED/M-IP68-Warm White LED Strip Light
SMD3528-60LED/M-IP68-Warm White LED Strip Light
Model: WDSMD- 3528-60
Port:Zhongshan, China
Production Capacity:100000 Meter/ Per Month
Payment Terms:L/C, T/T, Western Union, Paypal, Money Gram
Certification:LVD, RoHS, CE
Emitting Color:White
Voltage:DC12V/DC24V
IP Rating:IP68
Usage:Festival, Landscaping
Lead Time:in 7 Working Days
Description

Basic Info

Model NO.
WDSMD- 3528-60
Certificate
Ce, RoHS
Color
Multi-Color
Life(H)
50000 Hours
Trademark
WORLD-DAWN
Transport Package
5m/Roll, 1 Roll/Bag
Specification
1000x8x2.2mm
Origin
China
HS Code
9405409000

SMD3528-60LED/M-IP68-Warm White LED Strip Light

Product name: LED strip light (SMD3528-60-Warm white)
Item No.: WDSMD3528-60-Warm White
LED type: SMD 3528
LED Qty: 60 LEDs/ per meter
Size: 1000X8X2.2MM
Voltage: DC12V/DC24V/AC110V/220V
Beam angle: 120
Color: Red, Yellow, Blue, Green, White, Warm white, Pink
Packing: 5M/Roll, 1 Roll/bag
Total output lumens(LM/W): Red=18.75, Yellow=18.75, Blue=12.5, Green=50, White=62.5, Warm white=50

Encapsulation type:
Naked(NK) IP00
Waterproof tube(PC) IP68
One side filling glue another side ahere 3M tape, IP68
Full waterproof, PC+PU, IP68

Features:
Three LED bulbs to one section of the soft PCB, with double-sided tapes on the back for the paste, small size and easy to install
Standard length: 5M/ per roll
Color: Red, Yellow, Blue, Green, White, Warm white, Pink
Voltage: DC12V/DC24V/AC110V/220V
Apply to Signing the figure and route advertising

Application of LED Strip:
The product use for indoor lighting, shopping mall, super, market, showroom, club, store, hotel, restaurant, school, library, art gallery, museum, office building, home decoration. Replacement bulbs for general lighting, especially for museums, art galleries, cosmetic counters where UV or IR radiation is undesirable

Item LED Size LED Qty/ per meter(PC) Electric current Voltage Wattage/ per meter Beam angle Size Packing size
WDSMD-3528-30 SMD3528 30 0.2A DC 12V 2.4W 120° 1000X8X2.2mm 5M / per reel
WDSMD-3528-60 SMD3528 60 0.4A DC 12V 4.8W 120° 1000X8X2.2mm 5M / per rell
WDSMD-3528-96 SMD3528 96 0.64A DC 12V 7.6W 120° 1000X8X2.2mm 5M / per rell
WDSMD-3528-120 SMD3528 120 0.8A DC 12V 9.6W 120° 1000X8X2.2mm 5M / per rell
WDSMD-5050-30 SMD5050 30 0.6A DC 12V 7.2W 120° 1000X10X2.2mm 5M / per rell
WDSMD-5050-60 SMD5050 60 1.2A DC 12V 14.4W 120° 1000X10X2.2mm 5M / per rell
WD-SMD5050-30 RGB(full color chasing) SMD5050 30 1.94A DC 5V 9.7W 120° 1000X10X2.2mm 5M / per rell
WDSMD-3528-240 SMD3528 240 0.8A DC 24V 19.2W 120° 1000X14X2.2mm 5M / per rell
WDSMD-5050-120 SMD5050 120 1.2A DC 24V 28.8W 120° 1000X20X2.2mm 5M / per rell
 Red  ,         Blue,         Yellow,     Green,       Daylight  white,   Warm white   , RGB
